This is the latest version of our OB1 line designed to have a modern cottage look and feel, inside and out, yet still maintains the tall ceilings, lots of light and open floor plan we’re known for in the industry.
The living area features a tall 10’ ceiling with lots of glass to take advantage of natural light and outdoor views. The main level is 8’-6” x 20’-0” making it 170 sf of living space. The bedroom loft is 6'-0” wide x 7'-6” long making it 45 sf, and can easily fit a queen size mattress. The loft is accessed by a staircase with storage areas.
It has a full size bath with a large 30” x 52” shower area you won't find in most tiny homes. Spacious kitchen with a 6'-6” countertop area and room for a large 24" wide x 60" tall fridge.
This unit comes turn key with all fixtures and appliances included.
Chassis
20’-0” x 8’-6” wide
Two 7,000lb axles
Floor
T&G 3/4” subfloor
Closed cell spray foam insulation R-13
Vinyl plank flooring on vapor barrier
Walls
2x4 wood stud walls
T-111 3/4” siding with Hardie plank
House wrap vapor barrier
Spray foam insulation R-13
1/2” drywall finish
Ceiling
2x6 roof rafters
5/8” plywood sheathing
Peel and stick roof leak barrier
Galvalume 26ga metal roof
Spray foam insulation R19
Ship lap wood ceiling
Windows and door
Large 6’ x 6’-8” vinyl entry door with impact glass
All impact glass vinyl windows
Electric
30amp 120v service
LED 4” ceiling lights
Pioneer 12,000 btu AC with heat
Plumbing
Pex 1/2” cold and hot water supply
PVC waste water lines with 3” hookup
Propane water heater
Kitchen
Shaker gray cabinets
Tile backsplash
Quartz countertop
Stainless propane 2 burner cooktop
Stainless single bowl kitchen sink
Stainless faucet with pull down sprayer
Stainless 7.1 cu. Ft. fridge
Bath
Flushing toilet
Sink cabinet
Ceramic tiled shower
Pebble tile floor
NOAH RV certified
